Product Description
Pressed steel bearing housings provide a lightweight, cost-effective solution for supporting rotating shafts. They offer good strength, corrosion resistance, and easy installation, with multiple mounting styles to suit different applications. Ideal for light to medium-duty machinery and conveyor systems.
| Housing Type | 3-Bolt Flange |
| Material | Pressed Steel |
| Series / Model | PF206 |
| Compatible with | UC206, SB206, HC206 |
| Overall Dimensions (L x A x H) | 113mm x 19mm x 113mm |
| Inside Diameter | 62mm |
| Mounting Bolts | 3 x M10 |
| Bolt Hole Spacing | 90mm |
| Unit | Each |
