Product Description
A Section V Belts have a nominal top width of 13mm and a nominal thickness of 8mm (actual dimensions may vary slightly). They are used in medium to heavy drive systems that require power transmission of 1 HP or greater.
| Belt Section | A (4L) |
| Type | Wrapped Classical V Belt |
| Width Imperial | 1/2in |
| Width Metric | 13mm |
| Inside Length Imperial | 53in |
| Inside Length Metric | 1346mm |
| Outside Length Imperial | 55in |
| Outside Length Metric | 1397mm |
| Thickness Imperial | 5/16in |
| Thickness Metric | 8mm |
| Min Pulley Diameter | 75mm (per ISO/DIN/RMA guidelines) |
| Number of Bands | 1 |
| Material | Rubber |
| Reinforcement Material | Polyester |
| Weight | 0.168 |
| Unit | Each |
