Product Description
HTD 3M belts have a 3mm tooth pitch and are designed for compact, low-power applications requiring precise motion control. Ideal for small robotics, office equipment, and light-duty automation systems, they offer smooth, synchronous operation with minimal backlash.
| Belt Section | 3M |
| Type | HTD Timing Belt |
| Tooth Profile | M (Rounded) |
| Pitch Metric | 3mm |
| Width Metric | 5mm |
| Length Metric | 156mm |
| Number of Teeth | 52 |
| Max Speed | 20,000 rpm |
| Operating Temperature Range | -30°C to +100°C |
| Material | Neoprene with fibreglass cords |
| Unit | Each |
